*Works best with strong fluorophores. Please refer to CoolLED for further information
pE-800fura![]() | pE-800![]() | pE-4000![]() | pE-300ultra![]() | pE-300white![]() | pE-300lite![]() | pE-340fura![]() | pE-100![]() | pT-100![]() | |
---|---|---|---|---|---|---|---|---|---|
Description | Supercharged calcium imaging and beyond | 8-channel illumination, lightning-fast control | Research fluorescence illumination | Fast controllable illumination | Everyday controllable illumination | Simple white light for everyday fluorescence | LED Illumination for Fura-2 and common fluorophores | Single wavelength solution | Transmitted illumination |
Spectral Cover | 340 - 635 nm | 365 -770 nm | 16 selectable wavelengths spanning 365 -770 nm | 365 nm or 400 nm, 430 - 490 nm, 510 - 650 nm | 365 nm or 400 nm, 430 - 490 nm, 510 - 650 nm | 365 nm or 400 nm, 430 - 490 nm, 510 - 650 nm | 340 nm, 380 nm, 430 - 650 nm | 20 wavelengths to choose from (365 - 770 nm) | Broad white, 525 nm, 635 nm or 770 nm |
Fura-2 | |||||||||
DAPI | |||||||||
CFP | |||||||||
ChR2 | |||||||||
BCECF | |||||||||
FITC | |||||||||
YFP | |||||||||
TRITC & Cy3 | |||||||||
TexasRed & mCherry | |||||||||
Halo/NpHR | |||||||||
CY5 | |||||||||
Cy7, IRDye-800 | |||||||||
Inline excitation filter holders | |||||||||
Light delivery | LLG | LLG | LLG or Fibre | Direct Fit or LLG | Direct Fit or LLG | Direct Fit or LLG | Direct Fit or LLG | Direct Fit, LLG or Fibre | Direct Fit or LLG (WHT & 770 nm) |
Power consumption (at 100% irradiance) | 127 W | 127 W | 60 W | 46 W | 46 W | 46 W | 36 W | 25 W | 20 W |
Control Pod includes | The Lightbridge offers On/Off, Irradiance 0-100%, Channel control | The Lightbridge offers On/Off, Irradiance 0-100%, Channel control | On/Off, Irradiance 0-100%, Channel control | On/Off, Intensity 0-100%, Channel control | On/Off, Irradiance 0-100%, Channel control | White Light On/Off, Irradiance, 0-100% | On/Off, Irradiance 0-100%, Channel control | On/Off, Intensity, 0-100% | On/Off, Irradiance, 0-100% |
TTL | <7 µs | <7 µs | Global + Channel 20 μs switching | Global + Channel 20 μs switching, Sequence runner 20 μs switching | Global 20 μs switching | Global + Channel 20 μs switching Sequence runner 20 μs switching | Single TTL using BNC 150 μs switching | Single TTL using BNC 150 μs switching | |
Analogue | Individual channel control 0-10 V | Individual channel control 0-10 V | Individual channel control 0-10 V | ||||||
Software Via USB | NIS Elements, μManager, MetaMorph, HCImage, Inscoper, SlideBook & cellSens (using pE-6501-8-FR) | NIS Elements, μManager, MetaMorph, HCImage, Inscoper, SlideBook & cellSens (using pE-6501-8) | NIS Elements, cellSens, MetaMorph, LAS X, μManager, Andor iQ, HCImage, VisiView, SlideBook, Imspector Pro, Inscoper, & Volocity | NIS Elements, cellSens, MetaMorph, LAS X, μManager, Andor iQ, HCImage, VisiView, SlideBook, Imspector Pro, Inscoper, & Volocity | NIS Elements, cellSens, MetaMorph, LAS X, μManager, Andor iQ, HCImage, VisiView, SlideBook, Imspector Pro, Inscoper, & Volocity | NIS Elements, cellSens, MetaMorph, LAS X, μManager, Andor iQ, HCImage, VisiView, SlideBook, Imspector Pro, Inscoper, & Volocity | |||
Warranty | Industry-leading 36 months, or 3000 hours accumulated use of the 340 nm LED | Industry-leading 36 months | Industry-leading 36 months | Industry-leading 36 months | Industry-leading 36 months | Industry-leading 36 months | Industry-leading 36 months, or 3000 hours accumulated use of the 340 nm LED | Industry-leading 36 months | Industry-leading 36 months |
